Zirconium-vanadium-iron getter

Zirconium-vanadium-iron getter is a new type of non-evaporative getter with high adsorption performance and good stability. Its significant feature is that it can be activated at low temperatures to obtain excellent gettering performance. This getter can be used together with evaporative getter to enhance the gettering effect. This product is suitable for stainless steel insulation containers, camera tubes, X-ray tubes, and is widely used in vacuum tubes, infrared Dewars, vacuum switches, petroleum recording equipment, electric light sources, gas purification, and other fields. In addition to providing ribbon and sheet products with different sizes and specifications according to user needs, it can also provide disc-shaped structural products to facilitate user assembly and use.

ZC-001 Getter

ZC-001 getter is a new type of non-evaporable getter developed by our company. Its significant feature is that its activation temperature and operating temperature are lower than 707, and it has excellent gettering performance at room temperature and does not sinter at high temperatures. This getter can be made into sheet, strip, disc and other products according to customer's requirements. Due to its low activation temperature and good hydrogen absorption effect, it is widely used in stainless steel vacuum thermos flasks (cups), vacuum petroleum insulation pipes, and has significant effects compared to other products. ZC-001 getter can also be used in vacuum tube solar water heaters, vacuum switches, various vacuum devices, electronic tubes, gas purification and other fields.

Zirconium-vanadium-iron-titanium getter

ZC-002 getter is a new type of non-evaporable getter developed by our company based on ZC-001 getter. It is composed of a multi-element alloy of zirconium, vanadium, iron, and titanium. It is characterized by low cost and good low-temperature activation performance compared to 707 and other similar products. This product is particularly suitable for use in stainless steel vacuum thermos flasks (cups), vacuum glass, oilfield vacuum insulation pipes, and other products. It is also suitable for vacuum switches, industrial Dewars, and other products. This product can be made into sheets and strips according to customer requirements, and can also be pressed onto stainless steel metal carriers to make disc-shaped getters.

Zirconium-aluminum getter

Zirconium-aluminum getter is made by compressing zirconium-aluminum getter alloy powder into metal containers or coating it on metal strips. This type of getter can be used together with evaporative getter to enhance the gettering effect, and can also play a unique role in devices where evaporative getter is not allowed. This product comes in three forms: ring, strip, and disc. The strip getter uses advanced lining technology, and its gettering performance is significantly better than directly compressed products. This type of getter can be widely used in vacuum electronic devices and electric light sources such as metal halide lamps.

Zirconium-iron getter

Zirconium iron getter is a non-evaporable getter with lower activation and operating temperatures than zirconium aluminum getter. The getter can be made into sheet, strip, and granular shapes according to customer requirements. It is also possible to press metal powder onto a butterfly-shaped metal carrier to make a disc-shaped getter. Zirconium iron getter is particularly suitable for high-pressure discharge lamps (HID) due to its ability to not absorb nitrogen during the gettering process. This getter does not require special activation techniques and can be activated using high-frequency heating, radiant heating, or laser heating near the arc tube.

Mercury-release Getter

Mercury-releasing getter is mainly used in devices that require mercury filling. In addition to accurately releasing the required amount of mercury, it can also absorb harmful gases in the device. The use of mercury-releasing getter can also eliminate the mercury pollution associated with traditional liquid mercury injection methods. The company's mercury-releasing getter has two major series: tubular series and ribbon series. The tubular series features small size and good firmness, mainly used in backlight sources. The ribbon series can be cut to the required length according to the amount of mercury required, mainly used in various fluorescent lamps. In addition to being supplied in bundles, the ribbon series can also be provided in round rings according to customer requirements.

porous sintered getter

Porous sintered getter is made of various non-evaporable getter alloy powders sintered at high temperature. This type of getter has the advantages of low activation temperature, high gettering rate, large gettering capacity, good firmness, and no loose particles. Porous sintered getter is added with high-efficiency activator and anti-sintering agent to further improve its gettering performance. It can provide products in various shapes and sizes according to user requirements, and can also come with a heater for applications that cannot be activated by high frequency or thermal radiation. This getter can be widely used in infrared detection Dewar, X-ray tube and other vacuum devices.

Vacuum insulation panel (VIP) getter

The vacuum insulation board getter is a composite getter made by pressing calcium oxide desiccant, non-evaporative zirconium vanadium iron getter and barium lithium getter into a metal ring. The product has undergone high vacuum treatment and has a very low gas content. It not only has a strong water absorption function, but also has excellent gas absorption performance, including H2, CO2, O2, CO and organic gases. It is widely used in vacuum insulation boards for refrigeration and freezing or building insulation material boards to effectively adsorb residual gases and material outgassing inside the board, as well as gases that seep in during use, significantly improving the insulation effect and service life of the insulation board.
